- Meets the WLL performance requirements of BS EN 13157.
- Black Color finish.
- Drop forged screw type adjuster enables safe and speedy adjustment.
- Lightweight rugged construction.
- High grade steel sealed ball bearings for precise and smooth rolling.
- For use with hand and electric hoists.
- All trolleys are designed for use with same capacity HH Chain Blocks.
- Side plates are produced with trolley wheel guards for additional safety.
- Larger sizes available upon request.
Description
TECHNICAL DATA
| Product Code | WLL | Beam Range | A | B | C | D | Weight |
| (kgs) | (mm) | (mm) | (mm) | (mm) | (mm) | (kgs) | |
| GCL0.5T | 500 | 64-140 | 308.5 | 212 | 198.5 | 24 | 11.6 |
| GCL1T | 1000 | 76-165 | 328.5 | 255 | 231.5 | 30.5 | 17 |
| GCL2T | 2000 | 76-203 | 361.5 | 302 | 278 | 36 | 25.5 |
| GCL3T | 3000 | 88-203 | 428.5 | 344 | 338 | 45 | 39 |
| GCL5T | 5000 | 125-203 | 434 | 378 | 393 | 60 | 57 |
| GCL10T | 10000 | 136-203 | 487.5 | 455 | 490 | 82 | 93 |
| GCL20T | 20000 | 144-250 | 523 | 642 | 622 | 110 | 247.5 |
