Technical information:

  • .Manual stackers are commonly used in warehouses, factories, and distribution centers for various applications including:
  • Loading and unloading of goods from delivery trucks or containers.
  • Lifting and transporting pallets or goods to different areas of a warehouse or factory.
  • Stacking or lifting materials to heights of up to 10 feet for storage or production purposes.
  • Moving heavy equipment or machinery for maintenance purposes.
  • Working in congested areas or tight spaces where larger forklifts are unable to access.

Overall, manual stackers provide an economical and efficient
solution for material handling tasks, particularly for small to medium-sized businesses with limited budgets and space constraints.

Category:

Description

TECHICAL DIMENSION Model CTYD-1000
(mm)
CTYD-2000
(mm)
(Kgs) (mm) (mm)
Load capacity kg 1000 2000
Lifting Speed mm 33 21
Max lifting height mm 1600 1600
Overall length mm 1340 1360
Overall width mm 1600 1600
Overall Height mm 1960 2020
Fork Length mm 900 900
Single Fork Width mm 120 130
Front Wheel 80×60 80 × 70
Back Wheel mm 180 180
Net weight kg 140 160
20 FCL PSC 36 36
