Technical information:
- Drop forged , Cast steel , quenched and tempered.
- orange painted finsh .
- fitted with grab hooks.
- special securing device prevents threads coming out.
- Marked with L.C , Manfucters ID , size and product ID.
- Mill test certificate .
Description
| Product code | Chain Dia(Inch) | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | F(mm) | G(mm) | Take Up(mm) |
| HHLBR810 | 5/16 – 3/8 | 355 | 66 | 16 | 254 | 750 | 580 | 13 | 170 |
| HHLBR1013 | 3/8 – 1/2 | 355 | 66 | 16 | 254 | 770 | 600 | 16 | 170 |
| HHLBR1316 | 1/2 – 5/8 | 355 | 66 | 16 | 254 | 840 | 685 | 19 | 155 |
| Product code | Chain Dia(Inch) | Lashing Capacity(lbs) | M.B.L(lbs) | NET WEIGHT(kg) |
| HHLBR810 | 5/16 – 3/8 | 2450 | 8575 | 4.82 |
| HHLBR1013 | 3/8 – 1/2 | 4200 | 14700 | 5.92 |
| HHLBR1316 | 1/2 – 5/8 | 5900 | 20650 | 7.85 |
