Standard Configuration
- One transmitter (with hanging belt)
- One dust bag
- One receiver
- The receiver is with a 1.65m cable
- One receive antenna
- Operation and maintenance manual
Safety features
- Mechanical equipment safety 2006/42
- Priority Emergency Stop “Stop”
- According to EN61508 to SIL3 level based on EN13849-1 and 2, PLe performance level
- Electromagnetic compatibility EMC protection
- The system is with FCC and CE certificates.
Description
| Transmitter Parameters: F21-2S/2D-TX | |
|---|---|
| Material | Glass-Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | 425-446MHz |
| Transmitter power | ≤10dBm |
| Transmitter power supply | 2 AA batteries |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | -40℃~+85℃ |
| Control distance | Approx 100m (200m is customized) |
| Dimension | 156 × 61 × 51mm |
| Weight | 255g (without batteries) |
| Receiver Parameters: F21-RX | |
|---|---|
| Material | Glass-Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | 425~446MHz |
| Receiver sensitivity | -110dBm |
| Receiver power supply | 2 AA batteries |
| Output contact capacity | 8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
| Cable length | 1.65m (it can be customized) |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | -40℃~+85℃ |
| Dimension | 205 × 86 × 80mm |
| Weight | 620kg |
