- Meets the WLL performance requirements of BS EN 13157.
- Black Color finish.
- Drop forged screw type adjuster enables safe and speedy adjustment.
- Lightweight rugged construction.
- High grade steel sealed ball bearings for precise and smooth rolling.
- For use with hand and electric hoists.
- All trolleys are designed for use with same capacity HH Chain Blocks.
- Side plates are produced with trolley wheel guards for additional safety.
- Larger sizes available upon request.
Description
TECHNICAL DATA
| Product Code | WLL | Beam Range | A | B | C | D | Weight |
| (kgs) | (mm) | (mm) | (mm) | (mm) | (mm) | (kgs) | |
| GCT0.5T | 500 | 64-140 | 230 | 212 | 198.5 | 24 | 7 |
| GCT1T | 1000 | 76-165 | 254 | 255 | 231.5 | 30.5 | 12 |
| GCT2T | 2000 | 76-203 | 294 | 302 | 278 | 36 | 20.5 |
| GCT3T | 3000 | 76-203 | 344 | 344 | 338 | 45 | 33 |
| GCT5T | 5000 | 88-203 | 360 | 378 | 393 | 60 | 51 |
| GCT10T | 10000 | 125-203 | 403 | 455 | 490 | 82 | 86.5 |
